7495 4-Bit Shift Register with Parallel I/O

The 7495 4-Bit Shift Register with Parallel I/O is a versatile digital component designed for data storage and transfer in electronic circuits. With the capability to shift data serially while also providing parallel output, this shift register is ideal for applications such as data manipulation, temporary data storage, and interfacing with microcontrollers.

Key Features:

4-Bit Storage: Capable of holding 4 bits of data, making it suitable for various counting and data transfer applications.
Serial and Parallel Operation: Allows data to be shifted in serially while also enabling parallel output for simultaneous data retrieval.
Asynchronous Clear: Features a clear input to reset the register state, providing enhanced control over data handling.
Flexible Clocking: Operates with both positive and negative clock edges for versatile timing options.
TTL Compatible: Designed to work with standard TTL logic levels for easy integration into existing systems.

Benefits: The 7495 Shift Register is an essential building block for digital circuits, offering reliable performance and flexibility. It’s ideal for projects requiring efficient data storage, transfer, and processing, making it a valuable tool for engineers and hobbyists alike.

Target Audience: Electronics engineers, students, educators, and hobbyists engaged in digital circuit design and development.

Specifications

Type: 4-Bit Shift Register with Parallel I/O
Supply Voltage: Typically 4.75V to 5.25V
Input Levels: TTL compatible
Maximum Clock Frequency: Up to 5 MHz (varies with conditions)
Propagation Delay: Approximately 15 ns (depends on conditions)
Operating Temperature Range: -40°C to +85°C
Package Types: Available in DIP-16 and other configurations
