7473 Synchronous 4 bit Binary Counter with Reset

0 Orders 0 Wish listed

৳35

Qty

Total price:

৳35

Overview
Reviews

Detail Description

7473 Synchronous 4-Bit Binary Counter with Reset

The 7473 Synchronous 4-Bit Binary Counter is a versatile digital component designed for counting applications in electronic circuits. With synchronous operation and an easy-to-use reset feature, this counter is ideal for frequency division, event counting, and digital timer implementations.

Key Features:

4-Bit Counting Capacity: Capable of counting from 0 to 15 (binary), making it suitable for a wide range of counting applications.
Synchronous Operation: All flip-flops are triggered by a common clock signal, ensuring precise and predictable counting behavior.
Asynchronous Reset: Features a reset input that allows for immediate clearing of the count to zero, enhancing control over the counting sequence.
Parallel Load Capability: Enables loading of data into the counter, facilitating quick changes in the count state.
TTL Compatible: Designed to operate with standard TTL logic levels for seamless integration into digital systems.

Benefits: The 7473 Counter is an essential component for digital circuits, making it ideal for applications such as timers, frequency counters, and state machines. Its reliable performance and flexible operation make it a valuable tool for both hobbyists and professionals.

Target Audience: Electronics engineers, students, educators, and hobbyists engaged in digital circuit design and development.

Specifications

Type: Synchronous 4-Bit Binary Counter
Counting Range: 0 to 15 (4 bits)
Supply Voltage: Typically 4.75V to 5.25V
Input Levels: TTL compatible
Maximum Clock Frequency: Up to 10 MHz
Propagation Delay: Approximately 15 ns (varies with conditions)
Operating Temperature Range: -40°C to +85°C
Package Types: Available in DIP-16, SOIC-16, and other configurations
