74595 8-bit Serial-in Parallel-out Shift Register with Output Latches

Streamline your digital designs with the 74595 8-bit Serial-in Parallel-out Shift Register, an essential component for data storage and manipulation in various electronic applications. This versatile shift register allows for easy data management, making it ideal for interfacing with microcontrollers and other digital circuits.

Key Features:

• 8-Bit Storage: Capable of holding 8 bits of data, making it suitable for a wide range of applications, from simple data transfer to complex control systems.
• Serial Input, Parallel Output: Facilitates the transfer of data in a serial format while allowing parallel output, enabling efficient data handling.
• Output Latches: Each output pin has a latch that holds the output state, ensuring stable data output even when input changes.
• High-Speed Operation: Designed for fast data shifting, supporting clock frequencies up to 20 MHz (depending on supply voltage).
• Easy Integration: Compatible with various logic families, making it easy to incorporate into existing designs.

Benefits: The 74595 Shift Register is perfect for expanding the output capabilities of microcontrollers, controlling LEDs, or interfacing with displays. Its reliable performance and straightforward operation make it a valuable tool for both hobbyists and professionals.

Target Audience: Electronics engineers, students, educators, and hobbyists engaged in digital circuit design and development.

Specifications

• Type: 8-bit Serial-in Parallel-out Shift Register
• Logic Family: CMOS
• Supply Voltage: Typically 4.5V to 5.5V
• Input Voltage Levels: Compatible with standard TTL levels
• Data Propagation Delay: Approximately 25 ns (varies with conditions)
• Operating Temperature Range: -40°C to +125°C
• Package Types: Available in DIP-16, SOIC-16, and other forms
